Home/Cast Iron Valve/DN 100 GGG50 PN 16 Flange Gate Valve

DN 100 GGG50 PN 16 Flange Gate Valve

Write a review

Size: DN50—DN2200
Nominal Pressure: PN10/PN16
Working Temperature: -10°C~120°C
Suitable Medium: Chemicals,air,water,steam,oil, acids,salts,etc

Specifications

Size DN50-DN2200
Nominal Pressure PN10/PN16
WorkingTemperature -10°C~120°C
Suitable Medium Chemicals,air,water,steam,oil, acids,salts,etc

Standards

Design standard DIN3352 F4/F5, MSS SP-70,AWWA C509/515,BS5163
Face to Face DIN3202 F4/F5, BS5163, ANSI B16.10
Flange Drilling DIN2533 PN10/PN16, ANSI 125/150,JIS10K
Test Inspection DIN3230, BS6755

Materials

Body Cast Iron, Ductile Iron
Wedge Cast Iron, Ductile Iron
Stem Stainless steel,Brass
Sealing Ring EPDM,NBR
O Ring EPDM,NBR
