Globe Valve ANSI B16.10

Size: DN50—DN600
Nominal Pressure: PN10/PN16
Working Temperature: -10°C~120°C
Suitable Medium: Chemicals,air,water,steam,oil, acids,salts,etc


Nominal pressue (MPa) 1.0 1.6
Nominal diameter(mm) Shell 50-600 50-600
Test pressure Seal 1.5 2.4
(MPa) 1.1 1.76
Applicable temperature 150
Applicable medium Fresh water, Sewage, Sea water, Air, Vapor, Food, Medicine, Oils, Acids,
Alkalis, etc.
Operating mode manual, worm gear, pneumatic, electric, etc.


Design & Manufacture Flange Connection Face to Face Dimension Test&Inspection
MSS SP70 BS5152 BS5152

Material List:

NO. Part Name Material
1 Body Cast Iron/Ductile Iron
2 Body Seat Ring Cast Bronze
3 Reaction Member Brass
4 Disc Cast Bronze
5 Gasket Brass
6 Swivel Nut Cast Brass
7 Boll Steel
8 Body Gasket Graphite
9 Bonnet Cast Iron
10 Packing Graphite
11 Packing Gland Cast Brass
12 Gland Follower Ductile Iron
13 Gland Follower Bolts Steel
14 Gland Follower Nuts Steel
15 Stem Brass
16 Yoke Busing Cast Bronze
17 Screw Steel
18 Handwheel Cast Iron
19 Identification Steel
20 Handwheel nut Ductile Iron
